Description

9.7 mm Diameter Electret Condenser Microphone FET, 2 to 10V DC, 1K Ohm Impedance, 50 to 8 KHz Frequency

• Output Type: Analog
• Direction: Omnidirectional
• Frequency Range: 50 ~ 8 KHz
• Sensitivity: -42dB ±3dB @ 94dB SPL
• S/N Ratio: 60dB
• Impedance: 1k Ohms
• Voltage Range: 2 ~ 10V DC
• Current – Supply: 500 µA
• Port Location: Top
• Termination: PC Pins
• Size / Dimension: 0.382″ Dia (9.70mm)
• Height (Max): 0.264″ (6.70mm)
• Shape: Circular
